Sungye’s aluminum entry doors are designed for both commercial and residential building entrances, integrating anti-theft structure and fire retardant performance. Built with aerospace-grade alloy frames and multi-point locking systems, the doors also provide acoustic insulation for indoor spaces. The product supports custom adjustments to fit diverse architectural requirements, serving as a physical barrier for building access control and fire safety management.
The entry doors consist of three core structural components: reinforced alloy frames, high-density fire-retardant core filling, and integrated locking hardware. All key parameters are listed in the table below:
Category | Parameter Details |
|---|---|
Frame Material | Aerospace-grade aluminum alloy, 1.2mm reinforced core, 2mm galvanized protective layer |
Core Filling | Mineral wool insulation, 120kg/m³ density |
Locking System | Multi-point locking with 6 locking points, 15mm high-carbon steel deadbolt |
Fire Resistance | 30-minute structural integrity at 927°C |
Sealing System | EPDM rubber weatherstripping, 3mm compression rate |
Durability Test | 500-hour salt spray test passed, 25-year designed service life |
Certifications | CE Marking, ISO 10292, GB12955-2008 |
Surface Finish Options | Wood-grain finishes (oak, walnut, pine); metallic finishes (brushed bronze, stainless steel); custom panels with frosted glass or decorative grilles |
 |  |
The main frame uses a 1.2mm reinforced aluminum core with a 2mm galvanized protective layer. This design improves structural rigidity and delivers rust resistance for outdoor installation, reducing deformation risk under long-term daily use.
Filled with 120kg/m³ mineral wool, the door core restricts heat transfer and slows smoke spread during fire incidents. The material also adds acoustic insulation for indoor spaces.
The multi-point locking system includes 6 distributed locking points, secured by a 15mm high-carbon steel deadbolt. This layout covers typical structural weak points on door edges and resists forced entry attempts.
The doors maintain structural integrity for 30 minutes at 927°C in standard fire tests, preventing flame penetration during this period. This performance aligns with CE Marking and ISO 10292 requirements, and complies with GB12955-2008 standards, supporting building evacuation procedures in emergency situations.
EPDM rubber weatherstripping with 3mm compression rate is applied around the door frame. Compared with conventional sealing solutions, this design reduces air leakage by up to 80%. The airtight barrier blocks moisture infiltration and reduces heating and cooling energy consumption for buildings.
Multiple surface treatments are available for project procurement. Wood-grain finishes include oak, walnut and pine, which replicate the appearance of natural timber. Metallic finishes such as brushed bronze and stainless steel fit modern architectural styles. Custom panel designs with frosted glass inserts or decorative grilles are also supported for specific project requirements.
High-rise apartment buildings require entrance solutions that withstand high daily traffic and meet local fire safety codes. These doors support standardized installation for individual units, delivering intrusion resistance and fire protection for residential entrances and corridors.
Office facilities need access control solutions that align with corporate interior aesthetics. These doors secure restricted zones and main building entrances, while their acoustic insulation reduces outdoor urban noise to support indoor privacy for business operations.
Hospitals, clinics and hospitality facilities follow strict emergency evacuation rules and require quiet indoor environments. The weathertight seals block drafts and external noise, and the fire resistance performance meets public facility building codes and inspection standards.
With production experience since 1997, the factory provides entry door solutions for global infrastructure projects. All products pass 500-hour salt spray testing to verify corrosion resistance. A dedicated technical team offers 24/7 support for installation guidance and post-inspection services for global customers. Customization on dimensions, finishes and panel designs is available to match specific project requirements.
The doors have a 25-year designed service life, verified by 500-hour salt spray testing. Specific warranty terms and coverage scope are provided with formal quotations based on order specifications.
Yes. Standard finish options include oak, pine and walnut wood-grain styles, as well as brushed bronze and stainless steel metallic styles. Custom color and finish requirements can be discussed for bulk project orders.
Production and delivery timelines vary based on total order volume and customization requirements. Exact lead times are specified in the formal quotation after confirming order details.
Enterprise customers are welcome to visit the production facility in Foshan to view manufacturing processes and quality control systems on site. Visits can be scheduled in advance through our sales team.
